Product Description:
15 Inch Saw Touch Monitor With 420 Nits High Brightness Lcd 4/3
Ratio Display
SAW Touch Monitor Open Frame is a high-resolution, lightweight
touchscreen with an open frame design and HD resolution of
1024*768. It features a wide viewing angle of 80° and low power
consumption of 12W. This touchscreen supports VGA/DVI interface,
and its weight is only 3.5kg. With its excellent performance, it is
the perfect choice for demanding interactive applications such as
gaming, kiosks, and entertainment. Moreover, the open frame design
allows for easy access and installation in any space.
Specification:
| Complete Machine |
| Model No. | KOT-0150US-SA4BCW (P/N:KOT-150C-004) |
| Series | OT |
| Active Area | 304.1*228.1(mm) |
| Monitor Dimensions (W*H*D) | 336.4*264.4*43.9(mm) |
| Brightness (Typ.) | Pure LCD Panel | 420cd/m2 |
| With Touch Monitor | 378cd/m2 |
| Response Time (Typ.) | 5ms |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 80°/80° |
| Vertical(up/down) | 80°/80° |
| Video Input | VGA/DVI |
| Frequency (H/V) | 30～60KHz / 60～75Hz |
Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% |
| Storage Temp. | -20～60°C |
| Storage RH | 10%～90% |
| MTBF | 50,000 Hours |
| LED Back Light Life (Typ.) | 50,000 Hours |
| Weight(N.W/G.W) | 3.5Kg(1pcs)/11Kg(2pcs in one package) |
| Package dimensions | 429*183*356(mm)(2pcs in one package) |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤12W |
| Mount Interface | 1. VESA 75mm and 100mm 2. Mount bracket, horizontal or vertical mount |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V
Location, Languages, Function, Reset |
| Touch Screen Type | KeeTouch 15" SAW 4 mm Compact Touchscreen |
| Touch System Interface | Having USB and Serial(RS232) Interface |
| Touch Response Time | USB/Serial: 8.4/10.4ms |
| Agency
approvals | CCC, UL, FCC, CE, CB, RoHS |
| Regular Warranty | 1 year |
Applications:
KeeTouch's KOT-0150US-SA4BCW (P/N:KOT-150C-004) SAW Touch Monitor
is a high-definition touch screen monitor that is made in Shenzhen,
China and is certified by CCC, UL, FCC, CE, CB, and RoHS. It is
available in a minimum order quantity of 1pcs, with two pieces per
carton, and it is delivered within 7-15 work days. The payment
terms are T/T, Western Union,L/C, and the supply ability is 10000
Piece/Pieces per week. It has a power consumption of 12W, an
interface of VGA/DVI, a brightness of 420cd/㎡.
Customization:
KeeTouch SAW Touch Monitor (Model Number: KOT-0150US-SA4BCW
(P/N:KOT-150C-004), Place of Origin: In Shenzhen, China,
Certification: CCC, UL, FCC, CE, CB, RoHS) is designed for
industrial applications such as touch monitor open frame,
touchscreen open frame, capacitive touch screen kit, etc. It comes
with 15 Inch Screen Size, 800:1 Contrast Ratio, 5ms Response Time,
VGA/DVI Interface, and other features. The Minimum Order Quantity
is 1pcs, and the Price is Negotiable. The Packaging Details is two
pieces per carton, and the Delivery Time is 7-15 work days. We
accept payment through T/T, Western Union,L/C, and our Supply
Ability is 10000 Piece/Pieces per Week.
FAQ:
1. Are you a manufacturer?
Yes, KeeTouch is a reputable touch product manufacturer with over
17 years of experience, based in ShenZhen, China.
2. What is the warranty period for the SAW Touch Monitor?
Our standard warranty is 12 months for all products, with an
optional extension to 2-3 years.
3. Do you have stock?
Yes, we have a large quantity of stock for our regular model
products.
