19 Inch SAW Touch Monitor Anti-Vandal 1000:1 Contrast For ATMs
Description of SAW Touch Monitor
1. This product comes with SAW touch technology, fast response and
super interactive experience.
2.It is industrial grade SAW touch Monitor with anti-vandal and
IP65 front frame waterproof function.
3.VGA & DVI interfaces and USB port are provided for use.
Specification of SAW Touch Monitor
| Complete Machine |
| Model No. | KOT-0190US-SA4BCW (P/N:KOT-190C-013) |
| Series | OT |
| Display Type | 5:4 Ratio 19" TFT-LCD |
| Active Area | 376.32*301.06 (mm) |
| Monitor Dimensions (W*H*D) | 416*344*54(mm) |
| Suggested Resolution | 1280x1024 @ 60Hz |
| Support Colors | 16.7M |
| Response Time (Typ.) | 5ms |
| Contrast Ratio (Typ.) | 1000:1 |
| Video Input | VGA/DVI |
| Frequency (H/V) | 37.9 -80KHz/ 60～75Hz |
| Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
| MTBF | ≥50,000 Hours |
| LED Back Light Life (Typ.) | ≥50,000 Hours |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W |
| Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V
Location, Languages, Function, Reset |
| Regular Warranty | 1 year |
| Touch Screen |
| Touch Type | 19" Surface acoustic wave touch screen |
| Touch input | USB/RS232 |
| Response Time | ≤8ms(USB) ; ≤12ms(RS232) |
| Hardness | 7H |
| Light Transmittance | ≥90% |
| Active Area | 382*305(mm) |
| Thickness | 4±0.1(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
industrial touch monitor Mechanical Dimensions
Applications
hdmi touchscreen monitor are widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
Why choose us?
1. We are a leading provider of industrial grade touch products and
touch solutions for over 17 years.
2. Our core competence is differentiated product customization.
With over 40 professional R&D engineers, we can offer OEM and
ODM services to meet customer’s individual requirements.
3. Our company has been approved by ISO9001 and ISO14001, and with
the certifications CCC, UL, FCC, CE, CB, BIS, RoHS, etc. for the
products.
4. Professional after-sales team at any time to provide services to
customers.
Advantages of SAW Touch Monitor
1. Immunity to EMI/RFI interference: SAW touch technology is generally immune to electromagnetic
interference (EMI) and radio frequency interference (RFI), ensuring
reliable performance in environments with potential interference
sources.
2. Low maintenance: wireless touch screen monitor do not have any coating or layers that can wear out over time,
making them low maintenance and long-lasting.
3. Stylus compatibility: 24 lcd monitor can detect touch inputs from a variety of objects, including
fingers, gloves, and styluses. This makes them versatile and
suitable for a wide range of applications and user preferences.
FAQ
1. Can you produce the SAW Touch Monitor according to the
customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are
welcomed.
2. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
3. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk
production.
