    SAW Dust Proof Outdoor And Indoor Kiosk Touch Monitor 10.4 Inch

    Ask Lasest Price
    Brand Name : KeeTouch
    Model Number : KOT-104P-005
    Certification : CCC, UL, FCC, CE, CB, RoHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 Pieces per Week
    Delivery Time : 7-15 work days
    • Product Details
    • Company Profile

    SAW Dust Proof Outdoor And Indoor Kiosk Touch Monitor 10.4 Inch

    10.4 Inch SAW Monitor Touch Dust-Proof Outdoor And Indoor Kiosks


    Description of SAW Touch Monitor


    This 10.4 inch SAW touch Screen comes with main specifications as below: IP65 waterproof, dust-proof and vandal-proof, 4:3 ratio, 800*600 resolution, 500:1 contrast ratio. This industrial grade SAW touch monitor delivers super great interactive experience.What’s more, KeeTouch pays great importance to product quality, so all our products come with global certifications, such as FCC, CE, RoHS, UL, etc.


    Surface Acoustic Wave Touch Screen Specifications

    ItemContents
    Model No.KOT-0104U-SA4BP(P/N:KOT-104P-005)104P-005
    SeriesOT,Dust-proof
    Monitor DimensionsWidth: 257mm Height: 199mm Depth: 45.5mm
    Brightness(Typ.)Pure LCD Panel 300cd/m2
    With SAW Touch panel 270cd/m2
    Response Time(Typ.)30ms
    Viewing Angle (Typ.at CR>10))Horizontal(left/right) 75°/75°
    Vertical(up/down) 50°/60°
    Contrast Ratio(Typ.)500:1
    Video InputVGA,DVI,HDMI
    Frequency (H/V)30~80KHz / 60~75Hz
    Power SupplyType: External brick
    Input (line) voltage: 100-240 VAC, 50-60 Hz
    EnvironmentOperating Temp. 0~50°C
    Storage Temp. -20~60°C
    Operating RH: 20%~80%
    Storage RH: 10%~90%
    MTBF50,000 Hours
    LED Back light Life(Typ.)50,000 Hours
    Weight (N.W/G.W)2.25Kg(1pcs)/6.55Kg(2pcs in one package)(Approx.)
    Out package dimensions330×220×280(mm)(2 pcs in one package)
    Power Consumption7.15W Max.
    Standby power consumption1.12W
    Mount InterfaceMount bracket, horizontal or vertical and VESA mount
    (Standard mount brackets are supplied)
    OSD ControlButtons AUTO,+,POWER,-,MENU
    Function Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
    Touch screen Type10.4” SAW 4mm thickness of touch screen sensor
    Touch System InterfaceHaving USB interface
    Touch Response timeUSB: 8.4ms
    Regular Warranty1 year

    SAW Touch Display Mechanical Dimensions



    Best SAW Touch Screen Monitor Applications

    • Retail
    • Gaming
    • Kiosk
    • self-service
    • Finance
    • Transit
    • Conference
    • Education
    • Healthcare
    • public service
    • e-commerce
    • Hotels
    • restaurants


    Advantages of SAW Touch Monitor


    1. High Clarity: Surface Acoustic Wave Monitor maintain high clarity and contrast levels, even when viewed from different angles or under varying lighting conditions, providing a clear and vibrant display.


    2. High Sensitivity: SAW Touch Panel are highly sensitive and can detect even the slightest touch or gesture, providing a responsive and accurate user experience.


    3. Durability: SAW Touchscreen Monitor are highly durable and can withstand heavy usage, making them ideal for use in public places such as retail stores, museums, and airports.


    Why choose us?

    • 5 production lines including 3 touch screen lines,1 touch monitor line and 1 hardware accessories line.
    • Comply with ISO9001 quality system,ISO14001 environment management system and OC080000 limit harmful material management system certifications.
    • Branch offices widely spreads all over the world,such as Russia,Brazil,Germany and India etc.
    • Developing a large number of agents and distributors,offering world-wide sales networks and comprehensive after-sale service system.

    FAQ


    1. Are you a manufacturer?

    Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.


    2. What’s your MOQ for the SAW Touch Monitor?

    Our minimum order quantity is 1pc only.


    3. What is your warranty period for the SAW Touch Monitor?

    Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
