43 Inch multi touch capacitive screen IP65 Waterproof Open Frame
Touch Display
Description of multi touch capacitive screen
This 43 inch PCAP touch monitor adopts KeeTouch Projected
Capacitive touch technology with high resolution and ideal touch
experience. With PCAP multi touch, high sensitive and fast
response. This PCAP touch monitor is industrial grade, with high
quality image, durable and fashionable with dust-proof,
vandal-proof and IP65 waterproof functions. Moreover, other sizes
(7’’ - 43’’ ) can be offered for your option.
Specification of multi touch capacitive screen
| Complete Machine |
| Model No. | KOT-0430U-CA4P(P/N:KOT-430P-004) |
| Series | OT |
| Display Type | 16:9 Ratio 43" TFT-LCD |
| Active Area | 942.9*531.25 (mm) |
| Monitor Dimensions (W*H*D) | 1004*592*64.6 (mm) |
| Suggested Resolution | 1920x1080 @ 60Hz |
| Support Colors | 16.7M |
Brightness (Typ.) | Pure LCD Panel | 380cd/m2 |
| With Touch Monitor | 320cd/m2 |
| Response Time (Typ.) | 6.5 ms |
Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89° |
| Vertical(up/down) | 89°/89° |
| Contrast Ratio (Typ.) | 3000:1 |
| Video Input | VGA DVI HDMI |
| Frequency (H/V) | 30～80KHz / 60～75Hz |
Power Supply | Type: External brick Display voltage: DC 24V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
Environment | Operating Temp. | -10～50°C |
| Operating RH | 20%～80% |
| Storage Temp. | -20～60°C |
| Storage RH | 10%～90% |
| MTBF | 50,000 Hours |
| LED Back Light Life (Typ.) | 50,000 Hours |
OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V
Location, Languages, Function, Reset |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS |
| Touch Type | 43" Capacitive touch screens, antiglare and tempered type |
| Touch input | USB |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Regular Warranty | 1 year |
NOTE :
① The display SPEC. are adjusted according to the selected LCD
screen and touch screen
② The support system is adjusted according the specific system and
version.
PCAP Touch Monitor Mechanical Dimensions
Why choose us?
1. We are a leading provider of industrial grade touch products and
touch solutions for over 17 years.
2. Our core competence is differentiated product customization. With over 40 professional R&D engineers, we can
offer OEM and ODM services to meet customer’s individual
requirements.
3. Our company has been approved by ISO9001 and ISO14001, and with the
certifications CCC, UL, FCC, CE, CB, BIS, RoHS, etc. for the
products.
4. Professional after-sales team at any time to provide services to
customers.
Applications
PCAP Touch Monitor are widely used in industries such as retail,
gaming, kiosk, self-service, finance, transit, conference,
education, healthcare, public service, e-commerce, hotels,
restaurants, travel service, payment systems, museums, exhibitions,
smart home, subways, railway stations, control and operation
systems, airports, entertainments, etc.
FAQ
1.Can you produce the PCAP touch monitor according to the
customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are
welcomed.
2. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
3. What is your delivery time for the PCAP touch monitor?
3-5 work days for inventory orders, 7-15 business days for bulk
production.
