32 Inch PCAP Touch Monitor Open Frame Curved Design For Gaming

Ask Lasest Price
Brand Name :	KeeTouch
Model Number :	KOT-320P-026
Certification :	FCC, CE, CB, RoHS,UL
Price :	Negotiable
Payment Terms :	T/T, L/C, Western Union
Supply Ability :	10000 Pieces per Week
Delivery Time :	7-15 work days

Add to Cart

Product Details
Company Profile

32 Inch PCAP Touch Monitor Open Frame Curved Design For Gaming

32 Inch PCAP Touch Monitor Open Frame Curved Design for Gaming

Description of PCAP Touch Monitor

This PCAP touch monitor delivers main features as below: 1920*1080 resolution, 3000:1 contrast ratio, anti-vandal, IP65 front frame waterproof and dust-proof with wide viewing angle. This PCAP touch monitor is industrial grade with high quality, which can be normally used in harsh

Description of PCAP Touch Monitor

with the professional R&D department, OEM and ODM services can be offered.

Complete Machine
Model No.	KOT-0320U-CA5P (P/N:KOT-320P-026)
Series	OT
Display Type	16:9 Ratio 32" TFT-LCD
Active Area	698.4 x 392.85(mm)
Monitor Dimensions (WHD)	768.4456109.6(mm)
Suggested Resolution	1920x1080 @ 60Hz
Support Colors	16.7M
Brightness (Typ.)	Pure LCD Panel	250cd/m²
	With Touch Monitor	213cd/m2
Response Time (Typ.)	21ms
Viewing Angle(Typ.at CR＞10))	Horizontal(left/right)	89°/89°(Typ.)/80°/80°(Min.)
	Vertical(up/down)	89°/89°(Typ.)/80°/80°(Min.)
Contrast Ratio (Typ.)	2100:1 (Min.) /3000:1(Typ.)
Video Input	VGADVI
Frequency (H/V)	54.15～84.38KHz / 49～72Hz
Power Supply	Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment	Operating Temp.	0～50°C
	Operating RH	20%～80%
	Storage Temp.	-20～60°C
	Storage RH	10%～90%
MTBF	≥30,000 Hours
LED Back Light Life (Typ.)	≥30,000 Hours
Power Consumption	Standby Power: ≤2W / Operating Power: ≤40W
Mount Interface	VESA 200mm
OSD Control	Buttons	AUTO,+,POWER,-,MENU
	Function	Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Regular Warranty	1 year

Touch Screen
Touch Type	32" Capacitive touch screens
Touch input	USB
Response Time	≤14ms
Hardness	6H
Light Transmittance	≥85%
Support System	XP,WIN7,WIN8,WIN10,Linux,Android
Active Area	692.7*392(mm)
Thickness	3.8±0.2(mm)
Touch Test	≥50,000,000 times
Input Voltage	DC 5V±5%

PCAP Touch Monitor Mechanical Dimensions

Applications

Retail
Gaming
Kiosk
self-service
Finance
Transit
Conference
Education
Healthcare
public service
e-commerce
Hotels
restaurants

Advantages of PCAP Touch Monitor

1. High sensitivity and accuracy: PCAP touch monitors offer excellent touch sensitivity, allowing for precise touch input even with a light touch.

2. Multi-touch support: PCAP touch monitors can support multiple simultaneous touch inputs, enabling advanced gestures and providing a more intuitive user experience.

3. Durability: PCAP touch monitors are built with a robust, chemically-strengthened glass surface that is highly resistant to scratches, wear, and damage.

4. Optical clarity: The glass surface of a PCAP touch monitor provides excellent optical clarity, allowing for high-quality image reproduction.

5. Slim and lightweight design: PCAP touch monitors typically have a slim and lightweight profile, which makes them easy to integrate into various systems and installations.

FAQ

1. Are you a manufacturer?

Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.

2. What’s your MOQ for the PCAP touch monitor?

Our minimum order quantity is 1pc only.

3. What is your warranty period for the PCAP touch monitor?

Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
