23 Inch Antibacterial Touch Screen Monitor Antiglare Anti-Vandal
IP65
Antibacterial Touch Screen Main Features
- Using ion-exchange process, permanent antibacterial
- Ag+ antibacterial, security, broad-spectrum and long-acting, no
drug resistance
- With antibacterial function, the bacteria on the panel’s surface is
reduced by 99.9%
- Multi-points Antibacterial Touch Screen, PCAP touch panel, high
sensitive and fast-response
- High resolution, high contrast ratio Antibacterial Touch Screen, full viewing angle, perfect interactive experience
- Vandal-proof and dust-proof, IP65 surface waterproof
- VGA+DVI+HDMI interfaces,USB for touch
- Multiple mounting options, support system: XP,WIN7,WIN8,WIN10,
Linux, Android
- Other sizes are available (15’’- 43’’)
Antibacterial Touch Screen Specifications
| Complete Machine |
| Model No. | KOT-0230U-CA5P (P/N:KOT-230P-802) |
| Series | OT |
| Display Type | 16:9 Ratio 23" TFT-LCD |
| Active Area | 509.184*286.416(mm) |
| Monitor Dimensions (W*H*D) | 569*348.2*47.2(mm) |
| Suggested Resolution | 1920*1080 @ 60Hz |
| Support Colors | 16.7M |
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 |
| With Touch Monitor | 212cd/m2 |
| Response Time (Typ.) | 14ms |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89° |
| Vertical(up/down) | 89°/89° |
| Contrast Ratio (Typ.) | 1000:1 |
| Video Input | VGA/DVI/HDMI |
| Frequency (H/V) | 37.9～80KHz / 60～75Hz |
| Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% |
| Storage Temp. | -20～60°C |
| Storage RH | 10%～90% |
| MTBF | ≥30,000 Hours |
| LED Back Light Life (Typ.) | ≥30,000 Hours |
| Weight(N.W/G.W) | 7.7Kg(1pcs)/20.8Kg(2pcs in one package) |
| Package dimensions | 650*435*195(mm)(2pcs in one package) |
| Power Consumption | ≤19W |
| Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V
Location, Languages, Function, Reset |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS |
| Regular Warranty | 1 year |
| Touch Screen |
| Touch Type | 23" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤10ms |
| Hardness | 6H |
| Light Transmittance | ≥85% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 513.80*291.00(mm) |
| Thickness | 5.3±0.35(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD
screen and touch screen
② The support system is adjusted according the specific system and
version.
Antibacterial Touch Screen Mechanical Dimensions
Applications
Widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over
16 years, located in Shenzhen, China.
2. What’s your MOQ for the Antibacterial Touch Screen?
Our minimum order quantity is 1pc only.
3. What is your warranty period the Antibacterial Touch Screen?
Our regular warranty is 12 months for all the products, with 2-3
years Warranty (optional).
4. Can you produce the Antibacterial Touch Screen according to the
customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are
offered.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk
production.
