17 Inch Infrared Touch Monitor 5:4 Ratio with 250 Nits IR Touch
Screen
Infrared Touch Monitor Main Features
- Infrared touch screen, accurate touch and great interactive
experience.
- Support embedded,wall-mounted,rack-mounted,desktop,VESA support.
- IP65 grade water-proof,dust-proof for front panel.
- ICCC, ETL, FCC, CE, CB, RoHS certificate.
- Multiple mounting options include VESA mount, horizontal or
vertical brackets mount.
- VGA/DVI interface, USB for touch input.
- Support system: XP, WIN7, WIN8,WIN10, Linux, Android.
- Other sizes are optional (7’’- 32’’).
Infrared Touch Monitor Specifications
| Complete Machine |
| Model No. | KOT-0170U-IR3W(KOT-170P-021) |
| Series | OT |
| Display Type | 5:4 Ratio 17" TFT-LCD,LED backlight |
| Active Area | 337.3*270.3(mm) |
| Monitor Dimensions (W*H*D) | 381*313*52(mm) |
| Suggested Resolution | 1280*1024 @ 60Hz |
| Support Colors | 16.7M |
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 |
| With Touch Monitor | 135cd/m2 |
| Response Time (Typ.) | 5ms |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 85°/85° |
| Vertical(up/down) | 80°/80° |
| Contrast Ratio (Typ.) | 1000:1 |
| Video Input | VGA/DVI |
| Frequency (H/V) | 30～80KHz / 60～75Hz |
| Power Supply | Type: External brick |
| Display voltage: DC 12V±5% |
| Input (line) voltage: 100-240 VAC, 50-60 Hz |
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% |
| Storage Temp. | -20～60°C |
| Storage RH | 10%～90% |
| MTBF | ≥30,000 Hours |
| LED Back Light Life (Typ.) | ≥30,000 Hours |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W |
| Mount Interface | 1.VESA 75mm and 100mm |
| 2.Mount bracket, horizontal or vertical mount |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V
Location, Languages, Function, Reset |
| Agency approvals | CCC, UL, FCC, CE, CB, RoHS |
| Regular Warranty | 1 year |
|
| Touch Screen |
| Touch Type | 17" Infrared touch screen |
| Touch input | USB |
| Response Time | 20ms |
| Hardness | 7H |
| Light Transmittance | ≥90% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 339*271(mm) |
| Thickness | 9±1(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
Infrared Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
FAQ
1.How to ship to us from your factory?
Optional: Fedex/DHL/UPS/EMS, by air, by sea or to your China
forwarder.
2. What’s your MOQ for the infrared touch monitor?
Our minimum order quantity is 1pc only.
3. Do you support customization?
Yes. We are the manufacturer of Industrial Touch Screen and Touch
Monitor. And have professional R&D Team, could customized the
touch monitor according to your requirement.
4. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
5. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk
production.
