17 Inch SAW Touch Monitor VESA Mounted LCD Screen Display For Self
Service Kiosk
SAW Touch Monitor Description:
KeeTouch SAW touch monitor features scratch resistant glass, a
highly durable build and an IP rating. It's high contrast and high
resolution to deliver a superior image clarity. The stable, drift-free operation of Surface Acoustic Wave
touchscreen technology provides an accurate touch response measured
on three axes using a finger, gloved hand, or passive stylus. It's
well compatible with XP, WIN7, WIN8, WIN10, Linux, Android.
SAW Touch Monitor Specifications
| Complete Machine |
| Model No. | KOT-0170US-SA6BW (P/N:KOT-170W-003) |
| Series | OT |
| Display Type | 5:4Ratio 17＂Active matrix TFT-LCD |
| Active Area | 338*270 (mm) |
| Monitor Dimensions (W*H*D) | 391*323*54.5 (mm) |
| Suggested Resolution | 1280*1024 @ 60Hz |
| Support Colors | 16.7M |
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 |
| With SAW glass sensor | 225cd/m2 |
| Response Time (Typ.) | 30ms |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 160°(75°/85°) |
| Vertical(up/down) | 150°(70°/80°) |
| Contrast Ratio (Typ.) | 1000:1 |
| Video Input | VGA/DVI |
| Frequency (H/V) | 30～80KHz / 60～75Hz |
| Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% |
| Storage Temp. | -20～60°C |
| Storage RH | 10%～90% |
| MTBF | ≥30,000 Hours |
| LED Back Light Life (Typ.) | ≥30,000 Hours |
| Package dimensions | 466*185*403(mm)(2pcs in one package) |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤15W |
| Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V
Location, Languages, Function, Reset |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS |
| Regular Warranty | 1 year |
| Touch Screen |
| Touch Type | 17" Surface acoustic wave touch screen |
| Touch input | USB/RS232 |
| Response Time | ≤8ms(USB) / ≤12ms(RS232) |
| Hardness | 7H |
| Light Transmittance | ≥90% |
| Support System | XP,WIN7,WIN8,WIN10 |
| Touch Test | ≥50,000,000 times |
SAW Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
Our Advantages:
- More than 15 years professional experience in touch product industry;
- 200 staffs, 45 trained R&D engineers and design teams support OEM / ODM
projects;
- 5 production lines including 3 touch screen lines,1 touch monitor
line and 1 hardware accessories line;
- Branch offices widely spreads all over the world,such as Russia,Brazil,Germany and India etc;
- Developing a large number of agents and distributors,offering
world-wide sales networks and comprehensive after-sale service
system;
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over
16 years, located in Shenzhen, China.
2. What’s your MOQ for the SAW touch monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the SAW touch monitor?
Our regular warranty is 12 months for all the products, with 2-3
years Warranty (optional).
4. Can you produce the SAW touch monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
5. Do you have the SAW touch monitor in stock?
Yes, we have a large quantity of stock for our regular model
products.
6. Do you give any discount?
We will do utmost to support you with the competitive price, also
good service will be offered.
