IP65 Waterproof Infrared Touch Monitor 19 Inch Open Frame 1280×1024 Resolution

Ask Lasest Price
Brand Name :	KeeTouch
Model Number :	KOT-0190U-IR3W KOT-190P-042
Certification :	CCC, UL, FCC, CE, CB, RoHS
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	10000 Piece/Pieces per Week
Delivery Time :	7-15 work days

Add to Cart

Product Details
Company Profile

IP65 Waterproof Infrared Touch Monitor 19 Inch Open Frame 1280×1024 Resolution

19 Inch Open Frame Infrared Touch Monitor IP 65 Waterproof Touch Screen

Infrared Touch Monitor Main Features

Infrared touch screen, accurate touch, fast response, 1- 40 points optional
Support embedded,wall-mounted,rack-mounted,desktop,VESA support
IP65 grade water-proof,dust-proof for front panel.
Compatible with various industrial systems/application
Aluminum alloy shell,good mechanical properties,better performance of heat dissipation
CCC, ETL, FCC, CE, CB, RoHS certificate.
Support system: XP, WIN7, WIN8, Linux
Other sizes can be offered (7’’- 43’’)

Infrared Touch Monitor Specifications

Model No.	KOT-0190U-IR3W
Series	OT
Display Type	19＂Active Matrix TFT-LCD
Display Active Area	14.8＂(377mm)×11.9＂(301mm)
Suggested Resolution	1280×1024@60Hz
Support Colors	16.7M
Brightness(Typ.)	Pure LCD Panel			250cd/m2
	With SAW Glass			225cd/m2
Response Time(Typ.)	16ms
Viewing Angle	Horizontal(left/right):(85°/85°)
(Typ.at CR＞10))
	Vertical(up/down):(80°/80°)
Contrast Ratio(Typ.)	1000:1
Video Input	Analog RGB
Frequency(H/V)	30～80KHz / 60～75Hz
Power Supply	Type: External brick
	Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment	Operation Temp:		0～50°C
	Storage Temp:		-20～60°C
	Operation RH:		20%～80%
	Storage RH:		10%～90%
MTBF	50,000 Hours
LED Back light Life(Typ.)	50,000 Hours
Weight(N.W/G.W)	N.W :5.85Kg (Single)
Power Consumption	15W Max.
Standby power consumption	0.95W
Mount Interface	1)VESA 75mm and 100mm
	2)Mount bracket, horizontal or vertical(Standard mount brackets are supplied)
OSD Control	Buttons	AUTO,+,POWER,-,MENU
	Function	Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Touch screen Type	Keetouch 19" IR Touch Mointor
Support System	WinXP,Win7,Win8,Linux
Touch System Interface	Having USB interface
Touch Response time	16ms
Agency Approval	CCC,UL,FCC,CE,CB,RoHS
Regular Warranty	1 year

Infrared Touch Monitor Mechanical Dimensions

Applications

KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.

FAQ

1. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.

2. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.

3. What is your warranty period for the infrared touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).

4. Do you support customization?
Yes. We are the manufacturer of Industrial Touch Screen and Touch Monitor. And have professional R&D Team, could customized the touch monitor according to your requirement.

5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )

6. How to ship to us from your factory?
Optional: Fedex/DHL/UPS/EMS, by air, by sea or to your China forwarder.
