Industrial 32 inch Infrared Touch Monitor Open Frame Touchscreen
Infrared Touch Monitor Main Features
- Infrared multi touch panel, high quality touch experience
- IP65 surface waterproof, vandal-proof Infrared Touch Monitor
- High resolution, high contrast infrared touch monitor with wide
viewing angle
- Multiple mounting options include VESA mount, horizontal vertical
brackets mount
- VGA + DVI + HDMI interfaces,USB for touch
- Support system: XP, WIN7, WIN8,WIN10, Linux, Android
- Other sizes are optional (7’’- 32’’)
Infrared Touch Monitor Specifications
| Complete Machine |
| Model No. | KOT-0320U-IR4P (P/N:KOT-320P-010) |
| Series | OT |
| Display Type | 16:9 Ratio 31.5" TFT-LCD |
| Active Area | 698.4*392.85(mm) |
| Monitor Dimensions (W*H*D) | 756*453*75.7(mm) |
| Suggested Resolution | 1920x1080 @ 60Hz |
| Support Colors | 16.7M |
| Brightness (Typ.) | Pure LCD Panel | 280cd/m2 |
| With Touch Monitor | 252cd/m2 |
| Response Time (Typ.) | 8ms |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 85°/85° |
| Vertical(up/down) | 80°/80° |
| Contrast Ratio (Typ.) | 1000:1 |
| Video Input | VGADVIHDMI |
| Frequency (H/V) | 37.9～80KHz / 60～75Hz |
| Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% |
| Storage Temp. | -20～60°C |
| Storage RH | 10%～90% |
| MTBF | ≥30,000 Hours |
| LED Back Light Life (Typ.) | ≥30,000 Hours |
| Weight(N.W/G.W) | 13Kg(1pcs)/15Kg(1pcs in one package) |
| Package dimensions | 851*153*553(mm)(1pcs in one package) |
| Power Consumption | Standby Power: ≤2W / Operating Power: ≤40W |
| Mount Interface | 1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V
Location, Languages, Function, Reset |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS |
| Regular Warranty | 1 year |
| Touch Screen |
| Touch Type | 32" Infrared touch screen |
| Touch input | USB |
| Response Time | ≤32ms |
| Hardness | 7H |
| Light Transmittance | ≥90% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 702.6*395.8±0.5(mm) |
| Thickness | <5(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
Infrared Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over
16 years, located in Shenzhen, China.
2. How to ship to us from your factory?
Optional: Fedex/DHL/UPS/EMS, by air, by sea or to your China
forwarder.
3. What is your warranty period for the infrared touch monitor?
Our regular warranty is 12 months for all the products, with 2-3
years Warranty (optional).
4. Can you produce the infrared touch monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. Do you have stock?
Yes, we have a large quantity of stock for our regular model
products.
