43 Inch Infrared Touch Screen 10 Points Touch With Aluminum Frame
Infrared Touch Screen Main Features
Infrared touch panel, 10 points multi touch
HID* Plug & play driver free capability
Vandal-proof and IP65 front side waterproof infrared touch screen
Accurate touch and fast response with high light transparency
Touch media: finger, stylus or any opaque object
High durable infrared touch screen even in harsh environmental
conditions
USB interface for touch input, support various OS
Other sizes are optional (15’’- 86’’)
Infrared Touch Screen Specifications
| Model No. | WKMI-U0430A3-06-WR-10 |
| Housing | Aluminum |
| Outside Dimensions | 990.2±1mm(L)×578.4±1mm(W)×8.4±1mm(H) |
| Active Area | 944.2±1mm(L)×532.4±1mm(W) |
| Aspect Ratio | 16:9 |
| Size | 43 inch |
| Touch Activation Force | No minimum touch pressure required |
| Number of touch points | 10 touch points |
| Minimum Touch Object | A diameter of 6mm opaque objects |
| Touch Durability | 60,000,000 touch/cm² |
| Resolution | 32768 × 32768 |
| Driver free | HID* compatible, up to 40 touch points |
| Linearity Deviation | ±1mm |
| Fault Tolerance | Workable even 75% sensors are damaged |
| Frames per Second | Up to 450 fps |
| Response Time | 5-10ms |
| Light Transmission | 100% without glass |
| Operate System Support | Windows®7,Windows®8,Vista,XP,Mac® OS,Linux,Android |
| Power Supply | Signal USB Connection |
| Low Power Consumption | Operating ≤2W, Stand by ≤250mW |
| Electrostatic Discharge | Per EN61000-4-21995; Level 4. |
| Contact Discharge:8KV |
| Air Discharge:15KV |
| 15kV on USB Connector pins |
| Temperature | operating:-20oC ~ 70o C |
| storage:-40oC ~ 85oC |
| Humidity | operating:10% ~ 90% |
| storage: 10% ~ 90% |
| Certifications | FCC , CE, RoHS |
| Operating Environment | Indoor and outdoor |
| Applicative Screen | LED,LCD,PDP etc. |
Applications
Widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over
16 years, located in Shenzhen, China.
2. What’s your MOQ for infrared touch screen?
Our minimum order quantity is 1pc only.
3. What is your warranty period for infrared touch screen?
Our regular warranty is 12 month for all the products, with 2-3
years Warranty (optional).
4. Can you produce the infrared touch screen according to the
customer's requirement?
Sure, with 40+ Professional R & D engineers, OEM and ODM are
offered.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. What is your delivery time?
3-5 work days for inventory order, 7-15 business days for bulk
production.
