Touch Screen Frame Panel 43 Inch IP65 Front Side Waterproof With
USB Interface
Touch Screen Frame Panel Main Features
1.10 points touch (Multi touch)
2. Support zoom in/out, display rotation
3. USB interface, Drive free, plug and play
4. Supporting 10 points touch under Windows®7,Windows®8,Vista,XP,Mac® OS,Linux,Android
5. Stable, no-drift calibration performance
6. Vandaproof and abrasion-resistant screens, ideal for rugged
applications
7. Parallax-free performance for LCD displays
8. Sealable against contaminants
9. Operable in various light conditions, indoor and outdoor
Touch Screen Frame Panel Specifications
| Model No. | WKMI-U0430A3-06-WR-10 |
| Housing | Aluminum |
| Outside Dimensions | 990.2±1mm(L)×578.4±1mm(W)×8.4±1mm(H) |
| Active Area | 944.2±1mm(L)×532.4±1mm(W) |
| Aspect Ratio | 16:9 |
| Size | 43 inch |
| Touch Activation Force | No minimum touch pressure required |
| Number of touch points | 10 touch points |
| Minimum Touch Object | A diameter of 6mm opaque objects |
| Touch Durability | 60,000,000 touch/cm² |
| Resolution | 32768 × 32768 |
| Driver free | HID* compatible, up to 40 touch points |
| Linearity Deviation | ±1mm |
| Fault Tolerance | Workable even 75% sensors are damaged |
| Frames per Second | Up to 450 fps |
| Response Time | 5-10ms |
| Light Transmission | 100% without glass |
| Operate System Support | Windows®7,Windows®8,Vista,XP,Mac® OS,Linux,Android |
| Power Supply | Signal USB Connection |
| Low Power Consumption | Operating ≤2W, Stand by ≤250mW |
| Electrostatic Discharge | Per EN61000-4-21995; Level 4. |
| Contact Discharge:8KV |
| Air Discharge:15KV |
| 15kV on USB Connector pins |
| Temperature | operating:-20oC ~ 70o C |
| storage:-40oC ~ 85oC |
| Humidity | operating:10% ~ 90% |
| storage: 10% ~ 90% |
| Certifications | FCC , CE, RoHS |
| Operating Environment | Indoor and outdoor |
| Applicative Screen | LED,LCD,PDP etc. |
Applications
Widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
FAQ
1. What is your shipping method?
DHL, UPS, FedEx, TNT, Sea Freight.It depends on different customer.
2. Can you provide customized service for Touch Screen Frame Panel ?
We can make it according to your drawing, supply OEM and ODM
service.
3. Is the Touch Screen Frame Panel Driver-free? What OS can the ir touch screen panel kit support?
Yes, it is driver-free, it is “plug and use” type.Supporting 10 points touch under Windows®7,Windows®8,Vista,XP,Mac®
OS,Linux,Android
4. What is the MOQ? Sample of Touch Screen Frame Panel in stock?
No limited on MOQ, sample testing is ok. Standard size in stock.
5. What is the Touch Screen Frame Panel Application?
Widely used in open frame touch monitor, POS, ATM, KIOSK, Medical,
Media player, etc.
6. What is your warranty for Touch Screen Frame Panel ?
12 months warranty.
