32 Inch Infrared Frame Touch Screen 16:9 For Gaming Museums
Infrared Frame Touch Screen Main Features
* Works great on flat-panel monitors
* Good use of features. The touch force is very light, and there
are no special requirements for the touch body. Human fingers or
any object that blocks infrared light can be used as the touch
body.
* Highly adaptable. It is not disturbed by current, voltage and
static electricity, explosion-proof, dust-proof, and has strong
adaptability in harsh environmental conditions
* Long lasting life. It is durable and scratch-resistant, long touch
normal working time
Infrared Frame Touch Screen Specifications
| Item | Contents |
| Housing | Aluminum |
| Outside Dimensions | 742.5±1.5mm (L) ×430±1.5mm (W) ×9.4± 1.5mm(H) |
| Active Area | 698.4±1.5mm (L) ×392.9±1.5mm (W) |
| Aspect Ratio | 16:9 |
| Drawing | Refer to Appendix 7 |
| Size | 32 inch |
| Touch Activation Force | No minimum touch pressure required |
| Touch Durability | 60,000,000 touch/cm² |
| Resolution | 4096 × 4096 |
| Driver free | HID* compatible, up to 40 touch points |
| Linearity Deviation | ±1mm |
| Fault Tolerance | Workable even 75% sensors are damaged |
| Response Time | ≤20ms |
| Light Transmission | 92% with cover glass |
| Operate System Support | Windows®7,Windows®8,Vista,XP,Mac® OS,Linux,Android |
| Power Supply | Signal USB Connection |
| Low Power Consumption | Operating ≤1.4W, Stand by ≤250mW |
| Temperature | operating:0°C ~ 50°C |
| storage:-30°C ~ 60°C |
| Humidity | operating:0 ~ 95% |
| storage: 10% ~ 90% |
| Certifications | FCC , CE, RoHS |
Applications
Widely used in industries such as retail, gaming, kiosk,
self-service, finance, transit, conference, education, healthcare,
public service, e-commerce, hotels, restaurants, travel service,
payment systems, museums, exhibitions, smart home, subways, railway
stations, control and operation systems, airports, entertainments,
etc.
FAQ
1. Do you have stock for Infrared Frame Touch Screen?
Yes, we have 1000 units of various size and model for normal model
per month.
2. What is your warranty period?
Our regular warranty is 12 months for all the products.
3. Can you offer Infrared Frame Touch Screen according to the
customer's requirements?
Sure, with 40+ Professional R&D engineers, OEM and ODM are
offered.
4. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
5. What is your delivery time for Infrared Frame Touch Screen?
3-5 work days for inventory orders, 7-15 business days for bulk
production.
6. What’s your MOQ for Infrared Frame Touch Screen?
Our minimum order quantity is 1pc only.
