17 Inch PCAP All-In-One Touch Computer 1280×1024 Resolution
Industrial Touchscreen Computer Main Features
This PCAP all-in-one touch computer has anti-vandal and IP65
surface waterproof functions. With pure flat and narrow edge
design, the PCAP touch computer is very sleek and fashionable.
There are various configurations for your option, J1900, i3, i5
etc. It also supports operating systems: WIN7, WIN10, Android.
According to customers individual requirements, other sizes
(7’’-43’’) are available.
Industrial Touchscreen Computer Specifications
| KTP-170M-005 |
| Display | Screen | 17 inch |
| Resolution | 1280×1024 |
| According to the proportion | 5:4 |
| Brightness | 1000nit |
| Contrast | 1000:1(Typ.)/600:1(Min.) |
| Response Time | 5ms |
| View angle | 85/85/80/80(CR=10)/88/88/85/85(CR=5) |
| Active Display Area | 337.920×270.336mm |
|
| PC Configuration | CPU | Intel® 8th Gen Supports LGA 1151 CPU Up to 95W Max
Intel® 9th Gen Supports 4 core & 6 core CPU (TDP: 95W), 8 core CPU,
only support
CPU TDP up to 35W Max.
Intel® C246 Chipset |
| System Memory | Two 260-pin DDR4 2400/2666MHz SO-DIMM socket, supports up to 32GB
Max |
| BIOS | AMI uEFI BIOS, 256Mbit SPI Flash ROM |
| The operating system | Windows7/Windows10/Andriod(optional) |
|
| Touch Screen | Touch Method | Capacitive Touch |
| Touch Surface Hardness | 6H |
| Touch Screen Transparency | 85% |
|
| I/O interface | 1-VGA, 10-USB,4-LAN,2-HDMI, 1-DC,1-SWITCH, 1-PHONEIX TERMINAL |
|
| Other parameters | Cooling System | Fan |
| Enclosure Material | Metal |
| Waterproof Rating | IP65 ( Only for front panel ) |
| Power Consumption | ≤30W |
| Working Temperature | 0 ~ 50 °C |
| Storage Temperature | -20~60°C |
| Stroage Humidity | 20%~80% |
| Stroage Humidity | 10%~90% |
| Size | 418*355*98 (mm) |
| Warranty | 1 year |
| Certification | CCC, ETL, FCC, CE, CB, RoHS |
The Industrial Touchscreen Computer Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail,
gaming, kiosk, self-service, finance, transit, conference,
education, healthcare, public service, e-commerce, hotels,
restaurants, travel service, payment systems, museums, exhibitions,
smart home, subways, railway stations, control and operation
systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over
16 years, located in Shenzhen, China.
2. What’s your MOQ for the PCAP all-in-one touch computer?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the PCAP all-in-one touch
computer?
Our regular warranty is 12 months for all the products, with 2-3
years Warranty (optional).
4. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card,
Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
5. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk
production.
